The S48-APOE is a 48-port enterprise switch with full PoE+ on ALL ports. With 32 Gigabit ports, 16 2.5 GbE ports, 4 SFP+ 10G ports and a 740W PoE budget, it’s designed for the most demanding deployments.
Features Overview
PoE+ on all 48 Ports
16× 2.5 GbE + 32× GbE
4× SFP+ 10 Gbps
Scalable Cloud Management
Bluetooth Setup
Egress/Ingress Rate Limiting
VLAN Stacking
Rack/Wall Mount
802.1X Authentication
Full PoE+ on ALL Ports
The S48-APOE provides PoE+ on all 48 ports with a 740 Watt budget. The first 32 ports support up to 1 Gbps, the last 16 ports support up to 2.5 Gbps.
740W PoE budget — Up to 30W per port. Power all your devices on every port.
4 SFP+ Ports Up to 10 Gbps
4 SFP+ ports for high-capacity fiber or copper connections at 1, 2.5, 5, or 10 Gbps.
Bluetooth Setup
Simplified setup via Bluetooth using the Alta Networks mobile app.
Mounting Versatility
Included rack ears can be positioned for standard rack or wall mounting.
Scalable Cloud-Based Management
Intuitive cloud management interface included with your hardware purchase.
- Worldwide high-availability architecture
- Instant multi-site management
Specifications
| Gigabit Ports | 32× 10/100/1000 Mbps (PoE+) |
| 2.5 GbE Ports | 16× 10/100/1000/2500 Mbps (PoE+) |
| SFP+ Ports | 4× SFP+ (1/2.5/5/10 Gbps) |
| PoE+ | 48× PoE+ ports (all ports) |
| PoE Budget | 740 Watts |
| Switching Capacity | 240 Gbps |
| MAC Table | 32K entries |
| Dimensions | 440 × 310 × 44 mm |
| Weight | 4.99 kg (11 lbs) |
| Max Power | 890W (full PoE) |
| Mounting | 1U rack, wall |
| Certifications | CE, FCC, IC |
